FLYING High Speed Rapier Loom

Using advanced mechatronics technology, the performance is mature and stable, the economic speed is 400-450 r/min, and the maximum weft insertion rate is 1080 m/min. It is a high-speed intelligent loom with high cost performance.

Classification:

Rapier Loom

Hotline:

0757-88855989

Inquiry

FLYING High Speed Rapier Loom

Main drive: Main motor7.5KWAdopt frequency converter for speed regulation.

Insertion: The use of spatial four-bar linkage, forward and slow reverse search, accurate weft insertion action, is conducive to reducing driving marks.

Opening: Electronic dobby opening, up to 20 heald frame.

Electrical control system: Adopt 32-Bit CPU Central processor, frequency converter plus three-phase asynchronous motor.

Lubrication cooling system: Aluminum alloy oil tank, circulating spray lubrication, increase oil temperature sensor, forced water cooling to achieve the purpose of cooling oil temperature.

Color selection: Stepping motor controlled rotary high-speed electronic weft selector, color selection mechanism can be equipped with up to 16 Colors.

Beat up the weft: Double-sided conjugate cam, split sley.

Send on your way: Servo electronic let-off, digital closed-loop control constant tension weaving, from full shaft to empty shaft tension fluctuation is small.

Coiling: Servo electronic coiling, which can realize variable weft density weaving.

heald frame connection: It is convenient to adjust the height of heald frame and change varieties.
